6D-117-150 Tension clamp series

Three-bolt wedge tension clamp with the larger body in the family, for feeder-span conductor at dead-end and angle poles.

  • Model: 6D-117-150
  • Product Type: Tension Clamp

6D-117-150 is the larger body in the same wedge-type tension clamp family as 5D-93. Three bolts instead of two draw the wedge and body together, and the body is deep enough for the larger conductor sizes used on feeder spans.

Where it is used

It anchors bare or insulated overhead conductor at dead-end, angle and section poles where the span pull is beyond what a small body should carry. The cast eye at the tail takes a clevis or an insulator pin.

How it holds the conductor

The conductor sits in a tapered channel and the wedge is drawn in behind it, so the holding force rises with the pull on the line. The extra bolt spreads the clamping load along the body, which matters on larger conductor where a two-bolt body would crown at the middle.

Fixing and installation

Drive the wedge, then torque the three bolts in sequence from the centre bolt outwards. Check the cotter pin on the clevis pin after the conductor has been tensioned — this is the step most often skipped on site.

Filed under suspension clamps on this site, but 6D-117-150 is a tension (dead-end) clamp. It also shares its code with a small hanging clamp listed separately — the two are different products, so name the type when you order.

How to Select the Right Model

Confirm these before ordering:

ParameterValue
Conductor size and materialState the size
Rated tensile strengthSets the grip requirement
Body and wedgeAluminium alloy
HardwareGalvanised steel, three bolts
Insulated conductorState whether the insulation is removed at the clamp

The two figures that decide the model are the conductor diameter and its rated tensile strength. Neither can be inferred from the clamp number, so both are confirmed against your line data.

Sending an enquiry for 6D-117-150

One message with the conductor size, the pole or wall fixing and the quantity is enough for us to come back with the model, the grip value and a price. Drawings are welcome in place of a written description.
