SYDL-1 25-95mm² Suspension clamp series

Bolted suspension clamp for 25-95 mm2 with a polymer insulating eye, two studs and a keeper plate on the conductor groove.

  • Model: SYDL-1
  • Product Type: Suspension Clamp
  • Cross-Section / Cable Range: 25-95mm²

SYDL-1 is a bolted clamp: a galvanised body carrying a large polymer eye at one end, two threaded studs, and a keeper plate that closes the conductor groove. The eye is the part that insulates the clamp from whatever it hangs on.

Where it is used

It supports an insulated conductor of 25–95 mm² at an intermediate support, with the polymer eye taking the fixing point. Where the bracket or hook is metal, the eye is what keeps the conductor insulated from it.

How it holds the conductor

The conductor is laid in the groove and the keeper plate is drawn down by the two studs. Gripping over the full length of the plate rather than at a single point is what keeps the insulation intact on a suspended span.

Fixing and installation

Seat the conductor, fit the keeper plate, then tighten the two studs alternately to the specified torque. Do not overtighten to compensate for a conductor that is undersize for the groove — that crushes the insulation instead of holding the cable.

How to Select the Right Model

Confirm when ordering:

ParameterValue
Conductor cross-section25–95 mm², per the model designation
Fixing pointHook, bracket or pin — state the diameter
Body and studsGalvanised steel
EyePolymer, insulating
Tightening torqueConfirmed per order — the value depends on the stud size

Tightening torque is deliberately not printed here. On a bolted clamp the torque is set by the stud size and the conductor being held, and a figure quoted without those two leads to crushed insulation or a clamp that lets go. We send the torque with the order.

Sending an enquiry for SYDL-1

One message with the conductor size, the pole or wall fixing and the quantity is enough for us to come back with the model, the grip value and a price. Drawings are welcome in place of a written description.

Request a quotation

Send us the cable type and size, quantity and destination port for a quotation with pricing and lead time. View all suspension clamp models →
